产品规格：2050*900*500mm
产品配置：
ABS床头床尾板，床体、床腿由碳钢管焊接，酸洗磷化，静电喷塑。
床框采用40*80mm矩形钢管焊接而成，管壁厚度1.2mm
床面采用20*40mm矩形钢管焊接而成，管壁厚度1.2mm
床腿采用50*50mm矩形钢管焊接而成，管壁厚度1.2mm
单摇，背部折起角度0--70°，床眼包有翔胶脚套。
床面长度（不含床架）为:2050mm士10mm
床面宽度为:900mmt10mm
床面离地高度为:500mmt10mm
背框长度为:680mmt10mm
背框大折起角度为:>50
床的自重为:（净重）55.0Kg
产品介绍：
床体采用高频型钢焊接成型，结构合理、坚固耐用、表面喷塑处理。适用于不能下床或不便下床的病人，为他们提供休养、治疗及日常生活必须的特护服务，提高护理水平，改善病人生活质量，特别适合家庭、社区医疗护理机构、养老院、老年病医院使用。可附带餐桌，床体护栏及输液支架等配套设备

Product specifications: 2050*900*500mm

Product configuration:

ABS head and tail plate, bed body and legs are welded by carbon steel tube, pickling phosphating, electrostatic spraying.

The bed frame is welded with 40*80mm rectangular steel tube, and the thickness of tube wall is 1.2mm

The bed surface is made of 20*40mm rectangular steel pipe welded, and the thickness of pipe wall is 1.2mm

The bed leg is welded with 50*50mm rectangular steel tube, and the thickness of tube wall is 1.2mm

Single swing, back folded Angle 0-70 °, bed eyes covered with rubber foot cover.

The length of the bed surface (excluding the bed frame) is 2050mm and 10mm

The width of the bed is 900mmt10mm

The height of the bed from the ground is :500mmt10mm

The back frame length is 680mmt10mm

The large folding Angle of the back frame is >50

The dead weight of the bed is (net weight) 55.0Kg

Product Introduction:

The bed body adopts high frequency steel welding forming, reasonable structure, durable, plastic sprayed surface treatment. Suitable for patients who can not get out of bed or inconvenient to get out of bed, to provide them with recuperation, treatment and daily life necessary intensive care services, improve the nursing level, improve the quality of life of patients, especially suitable for families, community medical care institutions, nursing homes, geriatric hospitals. Table, bed guardrail, infusion support and other supporting equipment can be attached
