规格：2010*1020*500mm

产品配置：

实木护栏、床头及床尾板，床体、床脚由碳钢管机器人焊接而成，酸洗磷化静电喷塑。

床框采用40*80mm矩形钢管焊接，管壁厚度1.2~1.5mm

床面采用20水40mm矩形钢管焊接，管壁厚度1.2~1.5mm

床脚采用40*40mm方管焊接，管壁厚度1.5mm

不锈钢双摇手柄外部包裹ABS可折叠收缩摇把

背部折起角度0~70°（可调），背框大折起角度为>50

腿部折起角度0~45°(可调），床腿带有4只豪华ABS静音转向轮床面离地高度500mm士10mm

床体承重>240KG

Specification: 2010 * 1020 * 500 mm

Product configuration:

Solid wood guardrail, head and tail board, bed body and foot are welded by carbon steel tube robot, pickling phosphating electrostatic spray.

The bed frame is welded with 40*80mm rectangular steel tube, and the thickness of tube wall is 1.2~1.5mm

The bed surface is welded with 20 water 40mm rectangular steel tube, and the thickness of tube wall is 1.2~1.5mm

The foot of the bed is welded with 40*40mm square pipe, and the thickness of the pipe wall is 1.5mm

Stainless steel double handle wraps ABS collapsible shrink handle

The folding Angle of the back is 0° to 70° (adjustable), and the folding Angle of the back frame is >50

Leg folding Angle 0~45°(adjustable), bed leg belt has 4 luxury ABS silent steering gurney surface height of 500mm and 10mm

The bearing capacity of the bed is >240KG
