规格:2010*1020*500mm

产品配置:

实木护栏、床头及床尾板，床体、床脚由碳钢管机器人焊接而成，酸洗磷化静电喷塑。床框采用40*80mm矩形钢管焊接，管壁厚度1.2~1.5mm

床面采用20水40mm矩形钢管焊接，管壁厚度1.2~1.5mm

床脚采用40水40mm方管焊接，管壁厚度1.5mm

不锈钢单摇手柄外部包裹ABS可折叠收缩摇把

背部折起角度0~70°，背框大折起角度为>50°

床腿带有4只豪华ABS静音转向轮

床面离地高度500mm±1Omm

床体承重>240KG

Specification: 2010 * 1020 * 500 mm

Product configuration:

Solid wood guardrail, head and tail board, bed body and foot are welded by carbon steel tube robot, pickling phosphating electrostatic spray. The bed frame is welded with 40*80mm rectangular steel tube, and the thickness of tube wall is 1.2~1.5mm

The bed surface is welded with 20 water 40mm rectangular steel tube, and the thickness of tube wall is 1.2~1.5mm

The foot of the bed is welded with 40mm square pipe with a thickness of 1.5mm

Stainless steel single handle with ABS folding shrink rocker

The folding Angle of the back is 0° to 70°, and the folding Angle of the back frame is >50°

Bed leg strap has 4 deluxe ABS silent steering wheels

The height of the bed surface from the ground is 500mm±1Omm

The bearing capacity of the bed is >240KG
